MINERAL INSULATED BAND HEATERS
GENERAL FEATURES:
The mineral insulated band heaters are electrical resistors that offer high technical performance and density while maintaining high temperature applications surface really remarkable, thanks to the unique thermal mineral that allows for optimum heat insulation compared to traditional band heaters (mica or ceramic).
Innovative production techniques allow these band heaters made of mineral material of thermal insulation to get a really thin foil thermal insulation which provides excellent heat transfer between the resistive wire and the inner surface of the shell of the heater, as well as a lowering generalized surface temperature on the resistive wire and a consequent lengthening of the useful lifetime of the same heater.
This type of electric band heaters mineral-oxide insulated offers the user significant advantages in their use, including:
- These heaters can combine various types of specialty resins such as P.T.F.E. (Politetrafluoroetilene)
- Without adopting the same cumbersome attachment systems of the traditional band heaters, ensure easy installation.
- Allow to reach the working temperature is required in very small time compared to traditional band heaters, due to high heat and high surface density
Specifications:
- High surface density: 35.6 W / cm ² of heaters already reached a small diameter
- Maximum application temperatures up to 760 ° C
- Supply voltage up to 240V
- Outdoor Stainless Steel Armor
- High heat transfer in the heaters of limited size
USE:
- Extrusion machines, plastic machines and plastic injection molding
- Other applications that require heating of cylindrical shapes
CERTIFIED QUALITY PRODUCT
The entire production of mineral insulated band heaters to be subjected to stricter controls dimensional and electrical tests in accordance with regulations of our Company Quality System certified to ISO 9001:2008 and in full compliance with the requirements of current standards IEC / EN .
RESISTANCE STANDARD CATALOGUE
In the case of the standard application requirements, if there are no heating needs are particularly complex, we have in stock a range of models in mineral insulated band heaters with reduced delivery time.
SOME EXAMPLES:
For more details see the section “Download Area“
or request a quote online by filling out the “Quotation Request Form“
